ALUMINIUM END CAPS FOR TECHNICAL INSULATION
PVC END-CAPS
TERMINALI® PVC end caps are designed to create clean and clearly defined terminations at the ends of insulated pipes.
They cover exposed insulation edges and form a professional transition between the PVC jacketing and the adjacent pipe area. Available in different sizes and colours, they support a consistent appearance across professional technical insulation applications.
Multiple widths · Two roll lengths · Four available colours
.png)
Technical data
Property / Specification
PVC film
Density
1.36 g/cm³
Nominal thickness
0.5 mm ±2%
Available sizes
13/15, 18/20, 23/25, 28/30, 38/40, 48/50, 58/60, 68/70, 78/80, 88/90 and 98/100 ISO
Roll lengths
5 m and 10 m ±5%
Available colours
Isogenopak Grey, Nordic White, Sand Grey and Black
Temperature stability
Up to +50 °C
Fire classification
Class 1 (Italy) / B2 according to DIN 4102
Material characteristics
The PVC film is resistant to fats, acids and oils. It is physiologically and bacteriologically neutral and can be recycled.
Designed for professional insulation work
See TERMINALI® in action
TERMINALI® PVC end caps are used at the ends of insulated pipes to cover visible insulation edges and complete the transition between the PVC jacketing and the adjacent pipe area.
The appropriate size and colour should be selected according to the pipe dimensions, insulation thickness, jacketing system and installation requirements.
The roll format allows the material to be cut and adjusted on site before it is positioned and secured using a suitable fastening method.
FAST and EASY. Watch how the TERMINALI End Cap is prepared, adjusted and installed, to create a clean and professional finish on technical pipe insulation.
Benefits of
01
Professional TerMINATION
Covers exposed insulation edges and creates a clearly defined finish at the end of the insulation section.
TERMINALI® PVC combines flexible processing, reliable aluminium properties and a broad selection of versions for professional technical insulation work.
TERMINALI® PVC
02
Flexible
Roll format
Can be cut and adapted to different pipe dimensions, insulation thicknesses and application requirements.
03
COORDINATED
APPEARANCE
Available in four colours for a consistent finish with suitable PVC jacketing systems.
.png)
04
REsistant PVC MAterial
The PVC film is resistant to fats, acids and oils and is suitable for professional technical insulation applications.
